Shinobi 7 RX – 7″ Monitor & Receiver
Pre-order now. Ships end of October 2025
$799.00ex. TAX
Key Features
- 7-inch HDR screen with a peak brightness of 2200nits
- Professional monitoring tools include EL Zone/ARRI false color, histogram, waveform, zebra, focus peaking
- HDMI / 3G-SDI input and output
- Camera control over USB-C (see website for supported models)
- Touch to focus (see website for supported models)
- Integrated 5G Wi-Fi for low latency (<60ms) receive from Atomos TX
- Stunning 10+ stops of dynamic range in real-time from Log/PQ/HLG signals
- Dual NPF battery slots
SKU: ATOMSHBRX1
Categories: 7-Inch Monitors, Monitors, NEW
Pre-order now - ships end October 2025
Product Details
Shinobi 7 RX combines a larger 7-inch HDR screen with a calibrated peak brightness of 2200nits and the lightweight monitor-only functions of Shinobi. Can be used in the brightest of environments to monitor signals up to 4Kp60 via HDMI or HDp60 via 3G-SDI.
Camera Control
Take control of Canon, Fujifilm, Nikon, Panasonic, and Sony cameras via USB-C, plus Z CAM cameras via optional USB-C to serial cable.
Connectivity
The addition of Wi-Fi connectivity provides a stable link between the Shinobi 7 RX and the TX component of Atomos’ TX-RX wireless video system, or a RTSP H.264 stream. An ideal director’s monitor, focus puller’s monitor, program or preview display for video switchers.
What’s in the box?
- Shinobi 7 RX monitor
- USB-C 2.0 cable (1m)
- 2 x Wi-Fi antenna
- 5 x antenna tips
- Quick Start Guide
Physical
Dimensions (W x H x D mm)
198mm x 133mm x 39mm
Weight
580g (excluding batteries and antennas)
Mounting Points
1 x anti-rotation 1/4-inch top and bottom
Environmental
Ambient Operating Temperature
Up to 40 degrees Celsius
Construction
Body
ABS polycarbonate
Cooling
Passive heat sink
Power
Input voltage
6.2V - 16.8V
Operating power
5.8V - 7.2V
Multi-function button
Power / lock screen
Continuous power
Via NP-F battery or USB-C PD Power
DC in connector
Via Battery Eliminator (optional)
DTAP
Up to 13W
USB PD IN
45W capable, power supply required
USB PD OUT
Up to 13W
Display
Size
7-inch HDR screen with a calibrated peak brightness of 2200nits
Resolution
1920 x 1200
Backlight Type
Edge-lit
Brightness (cdm2 / Nits)
2200
Panel ratio
16:10
Color Gamut
Rec.709
Calibration support
Calibrite Display Pro or Display Plus on PC/Mac with Atomos LANC cable
Color Pipeline
Gamma
Sony SLog / SLog2 / SLog3 / HLG, Canon C-Log / C-Log2 / C-Log3, ARRI Log CEI160 / LogCEI200 / LogCEI250 / LogCEI320, / LogCEI400 / LogCEI500 / LogCEI640 / LogCEI800 / LogCEI1000 / LogCEI1280 / LogCEI1600, Panasonic V-Log / HLG, JVC J-Log, Red RedLogFilm / Log3G10 / Log3G12, FujiFilm F-Log, PQ (HDR10), HLG, Nikon N-Log
Gamut
BT.2020, DCI P3, DCI-P3 D65, Rec709. Sony: S-Gamut / S-Gamut3 / S-Gamut3.cine / BT.2020 / Rec.709. Canon Cinema: DCI P3 / DCI P3plus / Rec.709. Panasonic: V Gamut. ARRI: Alexa Wide Gamut. JVC: LS300. RED: DragonColor / DragonColor2 / RedColor2 / RedColor3 / RedColor4 / RedWideGamut
3D LUT Display
.Cube format (17 & 33 points supported)
3D LUT Down Stream
Loop out
3DLUT 50/50
Yes
Monitoring Modes
SDR Native / HDR HLG / HDR PQ / 709 LUT / User LUT
Video Input
HDMI
1 x HDMI (2.0)
Locking port
N/A
SDI
up to 1080p60
Wi-Fi
Wi-Fi 6E
USB
1 x USB-C 2.0/3.0
Bit Depth
8/10-bit video
Video Chroma Subsampling
4:2:2
Video Output
HDMI
1 x HDMI (2.0)
Locking port
N/A
SDI
1 x 3G-SDI
Wi-Fi
Wi-Fi 6E
USB
2 x USB-C 2.0/3.0
Bit Depth
8/10-bit video
Video Chroma Subsampling
4:2:2
Metadata
HDMI
N/A
Network
Wi-Fi
Wi-Fi 6E
Connectivity
LANC
Yes
Audio In/Out
HDMI
2-channel, 24-bit
SDI
8-channel, 24-bit
Headphone Out
3.5mm headphone jack, 2-channel
Timecode
Embedded
HDMI (display only)
Time of day
Yes
Reference / Genlock input
No
LTC
No
Resolution & Frame Rates
4K DCI
23.98 / 24 / 25 / 29.9 / 30 / 50 / 59.94 / 60p
4K UHD
23.98 / 24 / 25 / 29.9 / 30 / 50 / 59.94 / 60p
2K DCI 2048 x 1080
Yes
1080p
23.98 / 24 / 25 / 29.9 / 30 / 50 / 59.94 / 60 / 100 / 120p
1080 PsF
Converted to P and looped out PsF
1080i
50 / 59.94 / 60i
720p
50 / 59.94 / 60p
Supported Media
SD
To update firmware and upload LUTs
File System
FAT32, NTFS
On-screen Monitoring Tools
MultiScope Analysis View
Image, WFM, vector, histogram
Waveform
3 sizes – adjustable opacity & brightness
Histogram
1 sizes – adjustable opacity & brightness
RGB parade
3 sizes – adjustable opacity & brightness
Vectorscope
2 sizes – adjustable opacity & brightness
1 x Zoom
Yes. 1:1 pixel mapping for 4K
2 x Zoom
Yes
4 x Zoom
Yes
Focus peaking
4 modes (color, black & white, outline, edge sharpening) with adjustable outline color & peaking intensity
Atomos False Color
Yes, with scale
Zebra
Adjustable threshold (50% to 105%)
Isolate color channel
Blue Only
Cine Frame Guides
Presets for 2.41, 2.35, 1.91, 1.9, 1.85, 16:9
Social Frame guides
Presets for 9:16, 4:5, 2:3, 1:1, 5:4, 4:3, 3:2
Safe areas
SMPTE safe title area – 93% & 90%
Grid markers
9 grid
Anamorphic desqueeze
2x, 1.8x, 1.79x, 1.65x, 1.6x, 1.5x, 1.33x, 1.25x
Display Flip
Horizontal & vertical
External Device Control
USB-C
Camera control for supported cameras via USB-C. Controllable functions: Record Trigger, White Balance, Shutter Speed, Shutter Angle (if supported by camera), Aperture, ISO, Camera Overlays, Record Indicator, Touch to Focus - see Atomos website for camera model compatibility. USB-C port can also be used with external calibrators (no PC required).
Serial 2.5mm Jack
Calibration via optional USB to serial cable
What’s in the Box
Accessories included
Shinobi 7 RX monitor, Wi-Fi antenna, 5x antenna tips (black, white, yellow, green, red), 2 x antenna caps, USB-C 2.0 cable (1m), Quick Start Guide.
Warranty
Standard
1 year. Extended to 2 years on product registration.
