Shinobi 5″ (Used)
USA Only. B-stock – refurbished and demo units
$189.00ex. TAX
In stock
Key Features
- B-Stock USA Only
- 5″ compact camera monitor
- Refurbished or demo units
In stock - dispatched within 3 days
Product Details
Returned, refurbished or demo units – working as new!
5-inch, 1000nit HDR photo & video monitor
A lightweight HDR field monitor for the photographer or vlogger wanting to take their production to the next level and see images more clearly in any lighting conditions, in SDR or HDR. Shinobi is packed with an extensive suite of scopes, all accessible with simple one-touch operation.
In the box?
- Shinobi 5″ Monitor
- Battery Eliminator
- AC Power Cord
Physical
Dimensions (W x H x D mm)
151mm x 91.5mm x 31 mm / 5.95" x 3.6" x 1.2"
Weight
196g / 7oz.
Mounting Points
Top: 1 x 1/4"20, Bottom: 1 x 1/4"20
Environmental
Ambient Operating Temperature
Up to 40 Degrees Celsius
Construction
Body
ABS Polycarbonate Plastic
Cooling
Passively cooled
Multi-Function Button
Power / Lock Screen
Touch Screen
Capacitive Touch
Power
Input Voltage
6.2V to 16.8V
Compatible Batteries
1 x NP-F / L-Series
DC-In Connector
Via locking DC Jack (5.5mm OD & 2.1mm ID) on optionally available Battery Eliminator
D-Tap
Via optionally available Battery Eliminator & D-Tap to DC-Barrel Cable
Display
Display Panel
SuperAtom IPS Panel (Capacitive Touch)
Size
5.2"
Resolution
1920 x 1080
Viewing Angel
178 + H & V
PPI
423
Bit Depth
10-Bit (8+2 FRC)
Backlight Type
Edge-Lit
Brightness (cd/m² / nits)
1000
Aspect Ratio
16:9
Color Gamut
Rec.709
Calibration Support
ATOMOS Calibrator with Calibrite ColorChecker Display Pro or ColorChecker Display Plus
Color Pipeline
Gamma
Sony SLog / SLog2 / SLog3, Canon CLog / CLog2 / Clog3, Arri Log CEI160 / LogCEI200 / LogCEI250 / LogCEI320 / LogCEI400 / LogCEI500 / LogCEI640 / LogCEI800 / LogCEI1000 / LogCEI1280 / LogCEI1600, Panasonic Vlog, JVC JLog1, Red LogFilm / Log3G10 / Log3G12, FujiFilm Flog, PQ (HDR10), HLG, Nikon N-Log
Gamut
BT2020, DCI P3, PDCI p3 65, Sony SGamut / SGamut3 / SGamut3.cine, Canon Cinema / DCI P3 / DCI P3+ / BT2020, Panasonic V Gamut, Arri Alexa Wide Gamut, Rec709, JVC LS300, Red DragonColor / DragonColor2 / RedColor2 / RedColor3 / RedColor4 / RedWideGamut
3D LUT Display
.Cube Format (17 & 33 points supported)
3D LUT 50/50 Split
Via Compare Option in LUT Menu
Monitoring Modes
Native / 709 / HLG / PQ / 3D LUT
Color Management
Calibration
ATOMOS Calibrator with Calibrite ColorChecker Display Pro or ColorChecker Display Plus
Display Controls
Backlight, Lift, Gamma, Gain
AtomHDR
Built-in Technical Log to HDR EOTF
3D LUTs
Load .Cube files from SD Card into 8 LUT Slots On-Device & use for Monitoring
Video Input
HDMI
1 x HDMI (1.4)
Bit Depth
8 / 10-Bit
Chroma Subsampling
YCbCr 4:2:0 & 4:2:2
Audio In/Out
HDMI Embedded
2ch 24-Bit, Input dependent
Analog Audio Out / Headphone Jack
3.5mm Jack
Resolution and Frame Rates (Monitoring)
4K DCI
up to 4Kp30
4K UHD
up to UHDp30
FHD 1920 x 1080 Progressive
up to 1080p60
1280 x 720 Progressive
up to 720p60
Supported Media
SD Card
Used for Firmware Updates & Installing LUTs
File System
FAT & FAT32
On-Screen Tools
Waveforms
3 Sizes – Adjustable Opacity & Brightness
RGB Parade
3 Sizes – Adjustable Opacity & Brightness
Vector Scope
2 Sizes – Adjustable Opacity & Brightness
Histogram
1 Size – Adjustable Opacity & Brightness
MultiScope Analysis View
Image, Waveform, Histogram, Vector Scope & Audio Meters
1 x Zoom
Tap to Zoom
2 x Zoom
Tap to Zoom
4 x Zoom
Tap to Zoom
Focus Peaking
4 Modes (Color, Black & White, Outline, Edge Sharpening) with adjustable Outline Color & Peaking Intensity
Zebra
Adjustable Threshold (50% to 105%)
Isolate Color Channel
Blue Only
Cine Frame Guides
2.4:1, 2.35:1, 1.9:1, 1.85:1, 16:9, 4:3
Social Frame Guides
1:1, 5:4, 1:1.9
Safe Areas
SMPTE Safe Title Area – 93% & 90%
Anamorphic Desqueeze
2x, 1.5x, 1.33x
Display Flip
Horizontal & Vertical
Colorized Exposure
Atomos False Color
What's in the box
Box Contents
1 x Shinobi, 1 x International Power Supply, 1 x QuickStart Guide
Optional Extras
AtomX Monitor Mount, 5" Accessory Kit, Power Kit, HDMI Cables
Warranty
Standard
1 Year
